Product Dimensions 34.13"h x 23.88"w x 23.25"d
Easy to Store – Easy to Find. Your XO undercounter Beverage Center is the quick, convenient way to keep all your favorite beverages close at hand. The clear glass shelves fully extend while loaded to let you see and find everything at a glance. And because they easily adjust to 15 different positions, you can quickly configure the beverage center into your beverage center.Read More
Glass shelves extend fully while loaded to reveal contents
Secure door lock
Tri-color LED interior lighting
Shelves quickly adjust to 15 different positions
Intuitive digital temperature control from 34′ to 50′ F
Holds up to 145 (12oz) cans
Flush installation design
Energy-efficient Low-E Glass
Removable Wine Bottle Cradle included
X-Active circulation removes odors and circulates air
Quiet Operation 39 dBA
ENERGY STAR Certified Residential
Designed for residential or commercial settings
Field reversible door is shipped right-hand hinged
Clear glass shelves extend fully while fully loaded allowing you to see everything at a glance.
with easily adjusted electronic controls you can store your favorite beverages down to a frosty 34° .
is easy with features like zero clearance door hinges and flat electrical plugs. XO is designed to fit your life.
located in the stainless steel toe kick every XO undercounter model comes with a secure door lock to keep uninvited guests out.
Cool running LEDS are change with the push of a button from theater white to midnight blue or honey amber.
activated carbon filters and whisper quiet fans ensure the positive circulation of air for uniform temperatures.
On all glass door units, double pane, low-e glass coated to block harmful ultraviolet light is standard for energy efficient operation and protection from damaging light.
the 15" beverage centers include a 3 bottle display, while the 24" beverage centers include a 6 bottle display which are easily removed for additional storage or for use as a serving piece separately
every XO undercounter model comes with designer and pro-style handles to fit your decor.
General Specs | |
| Color | Stainless Steel |
| Color/Finish Name | Fingerprint Resistant Stainless Steel |
| Door Color | Fingerprint Resistant Stainless Steel |
| Handle Color | Fingerprint Resistant Stainless Steel |
| Total Capacity (cu. ft.) | 5.7 |
| Can Capacity | 145 |
| Installation Type | Built-In |
| Depth Type | Counter Depth |
| Door Panel Type | Glass |
| Door Swing Option | Right Hinge |
| Number Of Temperature Zones | Single Zone |
| Number of Shelves | 2 |
| Beverage And Wine Features | Interior Light, LED Temperature Controls, Dial Temp Control, Sabbath Mode |
| Under The Counter Capable | Yes |
| Custom Panel Ready | No |
| Wifi Capable | No |
| Smart Compatible | No |
| Locking Door | Yes |
| Light(s) | LED |
| Appliance Fit Width (in.) | 24 |
| Depth (in.) | 23.25 |
| Depth w/Door Open 90 Degrees (in.) | 46.5 |
| Width (in.) | 23.88 |
| Height (in.) | 34.13 |
| Overall Height (in.) | 34.13 |
| Shipping Depth (in.) | 29 |
| Shipping Width (in.) | 27 |
| Shipping Height (in.) | 37 |
| Product Weight (lbs.) | 124 |
| ENERGY STAR Certified | Yes |
| ADA Compliant | No |
| Voltage | 115 |
| Frequency | 60 |
| Amp | 1.2 |
More Imformation | |
Appearance | |
| Control Type: | Intuitive Touch Digital Controls |
| Toe Kick Color | Stainless |
| Interior Lighting: | Tri-Color LED Interior Illumination |
| Shelf Material: | Glass |
| Controls: | Electronic Touch |
| Control Lighting | Backlit LCD |
| Filter Type: | Activated carbon air filter |
| Light Colors: | Midnight Blue, Theater White, Honey Amber |
| Light Type: | Tri-Color LED Interior Illumination |
| Lighting Features: | Three lighting modes |
| Door Features: | UV Blocking Low-E Glass and Fingerprint Resistant Stainless Steel |
| Interior Finish: | Molded ABS |
| Open Door Alarm: | Yes |
Capacity | |
| Storage Features: | 15 Position Full Extension, Fully Loaded |
Performance Specifications | |
| Ambient Temperature: | 60 to 90 degrees F |
| Maximum Temperature Zone 1: | 50 degrees F |
| Minimum Temperature Zone 1: | 34 degrees F |
Weights & Dimensions | |
| Depth Excluding Handles: | 23.25 |
| Depth Including Handles: | 25 |
| Depth Less Door: | 21.88 |
| Side Clearance with Door Open 90 Degrees: | 1.75 |
| Height to Top of Door Hinge: | 34.13 |
Performance Specifications | |
| Ambient Temperature | 60 to 90 degrees F |
| Maximum Temperature Zone 1: | 50 degrees F |
| Minimum Temperature Zone 1: | 34 degrees F |
Installation | |
| Install Type: | Flush Undercounter |
| Location: | Indoor |
| Vent Location: | Bottom Front |
| Cut-out Depth: | 24 |
| Cut-Out Height | 34.25 |
| Cut-Out Width: | 24" |
| Cooling Unit Type: | Air Cooled Compressor |
| Refrigerant: | R600a |
| Defrost Type: | Automatic Defrost |
| Power Cord Included: | 6' with Flat Plug |
| Required Plug Type: | 5-15P Plug Type |
| Leveling Legs: | Included |
